Description
Display
Projection System
DLP
Resolution
SVGA(800x 600)
Brightness (ANSI lumens)
3600
Contrast Ratio (FOFO)
20,000:1
Display Color
1.07 Billion Colors
Native Aspect Ratio
Native 4:3 (5 aspect ratio selectable)
Light Source
Lamp
Light Source life*
Normal 5000 hours
Eco 10000 hours
SmartEco 10000 hours
LampSave 15000 hours
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200)
Light Source Wattage
200W
Optical
Throw Ratio
1.96~2.15
Zoom Ratio
1.1X
Clear Image Size (Diagonal)
30″~300″
Projection Offset**
110%±2.5%
Image Size
30″~300″
Keystone Adjustment
Vertical: ± 40 degrees‎
Horizontal Frequency
15K~102KHz
Vertical Scan Rate
23~120KHz
Audio
Speaker
2W
Interface
PC (D-sub)
X 1
Monitor out (D-sub 15pin)
X 1
S-Video in (Mini DIN 4pin)
X 1
Composite Video in (RCA)
X 1
HDMI
X 2
USB Type Mini B
X 1
Audio in (3.5mm Mini Jack)
X 1
Audio out (3.5mm Mini Jack)
X 1
RS232 (DB-9pin)
X 1
IR Receiver
X 2
Security Bar
X 1
Dimension and Weight
Net Weight (Kg/ lbs )
2.3 Kg
Dimensions (W x H x D)(mm)
296 x 120 x 221
Environment
Power Supply
AC 100 to 240 V, 50/60 Hz
Typical Power Consumption
270W
Standby Power Consumption
<0.5W
Acoustic Noise (Typ./Eco.)
33/29 dBA (Normal/Eco mode) ‎
Operating Temperature
0~40℃
Accessories (Standard)
Carton
Brown Carton, Hand Carry Type
Remote Control w/ Battery
x 1(RCX014)
Power Cord
Yes
Quick Start Guide
Yes
Warranty Card (by region)
Yes
VGA Cable
Yes
Accessories (Optional)
Spare Lamp Kit
Yes
Universal Ceiling Mount
Yes
3D Glasses
Yes
